QBD Series All-in-one Smart Solar Street Light, Integrated Solar Street Lamp For Solar 4G/LTE Solution With SSLS System

Smart Street Light is becoming more and more popular nowadays for smart city with energy saving. BOSUN lighting QBD series all in one solar street light with high power is very suitable for solar smart lighting solution, especially for the 4G/LTE solution. 4G/LTE solution is one of the most stable solutions for the solar smart lighting. With our patented SSLS (Smart Street Light System), it is much easier for the management of the lights on road, and it will be a intelligent way to achieve the smart city.

Model: QBD-S06/S08/S08PS/S10P

CCT: 3000K/4000K/6000K

Modules: 4/6/8/10 LEDS

Lumen Efficiency: 180lm/w

Beam angle: Beam angle: 70° * 150°

Smart Street Light Function: 4G

Corn Equipment: Lamp controller/Pro-double MPPT solar charge controller

Software: SSLS (Smart Street Light System)

Send email to us Product Manual

Product Detail

Product Tags

QBD-Series-All-in-one-Smart-Solar-Street-Light-1

QBD-Series-All-in-one-Smart-Solar-Street-Light-2

QBD-Series-All-in-one-Smart-Solar-Street-Light-3

BOSUN Smart Street Lighting System

Remote Control System(APP/PC/PAD)

√ Distributed deployment ,extendable RTU space
√ Keep the entire street lighting system in view
√ Easy to integrate with the third party system
√ Support multiple communication protocols
√ Convenient management entry
√ Cloud based system
√ Elegant design

Bosun smart lighting system can connect 1 million+ devices, you can achieve centralized control and management on our platform

Solar IoT (4G/LTE) Solution

Product Information

We Can Customized According to Your Project Requirments!

What Can We Offer You?

Core Equipment Introduction

Solar IoT (4G/LTE) Solar Light Controller

BS-SC-4G

The solar internet of Thinas module is a communication module that can adant tothe solar street amn controller This modulhas 4G Cat 1 communication function.which can be remotely connected to the server in the cloud, At the same time. themodulehas infrared /RS485/TTL communication interface, which can completethe sending and reading of the parameters and status ofthe solar controller. Mainperformance characteristics of the controller

- Cat1. Wireless communication
- Support remote upgrade firmware
- Two types of voltage input of 12V/24V - Module has base station positioning function
- Fault alarm, battery/solar board/load fault alarm
- Can remote switch load, adjust the power of the load
- Remote the parameters of multiple or single or single controller
- Read the voltage/current/power of the battery/load/sunglasses inside thecontroller
- You can control most of the mainstream solar controller in China throughRS232 communication
- Remote control and information reading of the computer interface and mobile phone

Solar Charge Controller

BS-Pro-Double MPPT(IOT)

Professional design to improve system reliability in an all-round way lnternational famous brands such as IR, Tl, ST, ON and NXP are used for semiconductor devices. lndustrial MCU ful digital technology, without any adjustable resistance, strong ant-interference ability, no aging and drift problems Ultra-high charging efficiency and LED driving efficiency, significantly reducing the temperature rise of products. IP68 protection grade, without any buttons, further improving waterproof reliability

Flexible parameter setting function
Support 2.4G communication and infrared communication
Battery reverse connection protection
Under-voltage protection for battery failure Reverse connection protection of solar panels
LED transmission short circuit protection,Prevent the battery from discharging to the solar panel at night
LED transmission open circuit protection
Battery undervoltage protection
Intelligent storage battery management
lntelligent charging management, patent Pro-Double-MPPT chargingconstant voltage charging and constant voltage floating charging.
lntelligent charge and discharge management based on temperature compensation can greatly prolong the service life of the battery by more than 50%.
lntelligent eneray management of storage battery ensures that the storage battery works in a shallow charge-discharge state, greatly prolonging the service life of the storage battery

High conversion efficiency
The efficiency of constant current driving LED is as high as 96%

Intelligent LED management
Light control function, automatically turn on the LED in dark and turn off the LED at dawn.
Five-period control
Dimrning function, different power can be controlled in each time period. Have morning light function.
lt also has the function of time control and morning light ininduction mode
