Bosun High Quality Pure Sine Wave Inverter 0.3KW-1KW 1.5KW-5.6KW

Hybrid power system, power all kinds of appliances in home or office environment; Running without battery; Pure sine wave inverter;
Configurable input voltage for home appliances and personal computers via LCD setting; Smart battery charger design for optimized battery
performance; Auto restart while AC is recovering; Cold start function; Compatible to mains voltage or generator power; Overload/ Over
temperature/ short circuit protection; Configurable battery charging current based on applications via LCD setting

Model : BS-SS-INW

Input Voltage Range: 85-138VAC/170-275VAC

Output Change Time: <10ms(Typical load)

MPPT Efficiency: >99%

Send email to us Product Manual

Product Detail

Product Tags

Product Features

● Pure sine wave inverter
● Inverter running without battery
● Configurable input voltage range for home appliances and personal computers via LCD setting
● Configurable battery charging current based on applications via LCD setting
● Configurable AC/Solar Charger priority via LCD setting
● Compatible to mains voltage or generator power
● Auto restart while AC is recovering
● Overload/ Over temperature/ short circuit protection
● Smart battery charger design for optimized battery performance
● Cold start function

Hybrid Power System

This inverter can power all kinds of appliances in home or office environment, including motor-type appliances such as tube light, fan, refrigerator and air conditioner.

Product Instruction

①——AC indicator
②——Status indicator
③——Charging indicator
④——Fault indicator
⑤——LCD display
⑥——Function buttons
⑦——Circuit breaker
⑧——AC input
⑨——AC output
⑩——RS-232 communication port
⑪——USB communication port
⑫——Dry Connection
⑬——Battery input
⑭——Power on/off switch
⑮——PV input
